技術參數Technical data
壓力范圍Pressure range: 0-16bar
介質溫度Medium temperature: -10℃～+180℃
環境溫度Environmental temperature: -10℃～+60℃
規格Specification: DN15-DN100,1/2＇-4＇
控制壓力Pressure control: 3-8bar
閥體材料Body material: 不銹鋼Stainless steel，CF8/304,CF8M/316
密封材料Sealing material: 聚四氟乙烯PTFE
執行機構外殼Actuator material: 聚酰胺PA
介質Medium:中性氣體、空氣、水、蒸汽 Neutral gas, air, water, Vapor
法蘭標準Flange standard:  GB,ANSI,DIN,JIS
特點：雙作用、單作用、防水錘
